5-16" SPEED PIN RIVET

 5-16" SPEED PIN RIVET

 ADVANTAGES OF SPEED PIN RIVET (DRIVE PIN RIVET):

  SPEED PIN RIVET IS FAST AND EASY TO INSTALL.

  NO SPECIAL INSTALLATION TOOL IS REQUIRED FOR SPEED PIN RIVET, JUST A HAMMER WILL DO.

  VARIOUS MATERIALS ARE AVAILABLE FOR SPEED PIN RIVET.

  VARIOUS HEAD STYLES ARE AVAILABLE FOR SPEED PIN RIVET.

  SPEED PIN RIVET IS EASY TO UNINSTALL, AND IT WILL NOT DAMAGE THE APPLICATION SURFACE.

  SPEED PIN RIVET CAN BE RUST RESISTANT.

  SPEED PIN RIVET CAN BE APPLIED TO WIDE THICKNESS.

 ★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

MATERIAL AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
BODY: ALUMINUM 2117 /STAINLESS STEEL 302 (INOX A2/18-8) / STEEL
PIN: ALUMINUM 2024 /STAINLESS STEEL 304 (INOX A2/18-8) /STEEL

FINISH SURFACE AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET): :
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED
ANODIZED/CLEAN

5/16" DIAMETER	PARTNUMBER	(L) LENGTH		GRIP RANGE (G)
		(INCH)	(MM)	NOM.		MIN.		MAN.
				(INCH)	(MM)	(INCH)	(MM)	(INCH)	(MM)
UNIVERSAL HEAD	TSP8.0S-1	0.437	11.100	0.188	4.775	0.132	3.353	0.242	6.147
	TSP8.0S-2	0.531	13.487	0.281	7.137	0.226	5.740	0.336	8.534
	TSP8.0S-3	0.625	15.875	0.375	9.525	0.320	8.128	0.430	10.922
	TSP8.0S-4	0.719	18.263	0.469	11.913	0.414	10.516	0.524	13.310
	TSP8.0S-5	0.813	20.650	0.563	14.300	0.508	12.903	0.618	15.697
