3-16" SPEED PIN RIVET

3-16" SPEED PIN RIVETS

ADVANTAGES OF SPEED PIN RIVET (DRIVE PIN RIVET):

• SPEED PIN RIVET IS FAST AND EASY TO INSTALL.
• NO SPECIAL INSTALLATION TOOL IS REQUIRED FOR SPEED PIN RIVET, JUST A HAMMER WILL DO.
• VARIOUS MATERIALS ARE AVAILABLE FOR SPEED PIN RIVET.
• VARIOUS HEAD STYLES ARE AVAILABLE FOR SPEED PIN RIVET.
• SPEED PIN RIVET IS EASY TO UNINSTALL, AND IT WILL NOT DAMAGE THE APPLICATION SURFACE
• SPEED PIN RIVET CAN BE RUST RESISTANT.
• SPEED PIN RIVET CAN BE APPLIED TO WIDE THICKNESS.
• THE APPEARANCE LOOKS GOOD AFTER INSTALLATION.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

MATERIAL AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
BODY: ALUMINUM 2117 /STAINLESS STEEL 302 (INOX A2/18-8) / STEEL
PIN: ALUMINUM 2024 /STAINLESS STEEL 304 (INOX A2/18-8) /STEEL

FINISH SURFACE AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET): :
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED
ANODIZED/CLEAN

SPEED PIN RIVETS

3/16" Diameter	PARTNUMBER	(L)LENGTH		GRIP RANGE(G)
		(inch)	(mm)	NOM.		MIN.		MAN.
				(inch)	(mm)	(inch)	(mm)	(inch)	(mm)
UNIVERSAL HEAD	TSP4.8S-1	0.250	6.350	0.094	2.388	0.047	1.1938	0.141	3.581
	TSP4.8S-2	0.281	7.137	0.125	3.175	0.078	1.981	0.172	4.369
	TSP4.8S-3	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP4.8S-4	0.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP4.8S-5	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP4.8S-6	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP4.8S-7	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP4.8S-8	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP4.8S-9	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP4.8S-10	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
	TSP4.8S-11	0.844	21.438	0.688	17.475	0.641	16.281	0.735	18.669
	TSP4.8S-12	0.906	23.012	0.750	19.050	0.703	17.856	0.797	20.244
	TSP4.8S-13	0.969	24.613	0.813	20.650	0.766	19.456	0.860	21.844
	TSP4.8S-14	1.031	26.187	0.875	22.225	0.828	21.031	0.922	23.419
	TSP4.8S-15	1.156	29.362	1.000	25.400	0.953	24.206	1.047	26.594
	TSP4.8S-16	1.281	32.537	1.125	28.575	1.078	27.381	1.172	29.769
BRAZIER HEAD	TSP4.8B-1	0.250	6.350	0.094	2.388	0.047	1.194	0.141	3.581
	TSP4.8B-2	0.281	7.137	0.125	3.175	0.078	1.981	0.172	4.369
	TSP4.8B-3	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP4.8B-4	0.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP4.8B-5	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP4.8B-6	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP4.8B-7	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP4.8B-8	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP4.8B-9	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP4.8B-10	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
	TSP4.8B-11	0.906	23.012	0.750	19.050	0.703	17.856	0.797	20.244
	TSP4.8B-12	0.969	24.613	0.813	20.650	0.766	19.456	0.860	21.844
	TSP4.8B-13	1.031	26.187	0.875	22.225	0.828	21.031	0.922	23.419
	TSP4.8B-14	1.094	27.788	0.938	23.825	0.891	22.631	0.985	25.019
	TSP4.8B-15	1.156	29.362	1.000	25.400	0.953	24.206	1.047	26.594
COUNTERSUNK HEAD	TSP4.8C-1	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP4.8C-2	0.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP4.8C-3	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP4.8C-4	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP4.8C-5	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP4.8C-6	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP4.8C-7	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP4.8C-8	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
