1-4" SPEED PIN RIVETS

1-4"SPEED PIN RIVETS

ADVANTAGES OF SPEED PIN RIVET (DRIVE PIN RIVET):

• SPEED PIN RIVET IS FAST AND EASY TO INSTALL.
• NO SPECIAL INSTALLATION TOOL IS REQUIRED FOR SPEED PIN RIVET, JUST A HAMMER WILL DO.
• VARIOUS MATERIALS ARE AVAILABLE FOR SPEED PIN RIVET.
• VARIOUS HEAD STYLES ARE AVAILABLE FOR SPEED PIN RIVET.
• SPEED PIN RIVET IS EASY TO UNINSTALL, AND IT WILL NOT DAMAGE THE APPLICATION SURFACE
• SPEED PIN RIVET CAN BE RUST RESISTANT.
• SPEED PIN RIVET CAN BE APPLIED TO WIDE THICKNESS.
• THE APPEARANCE LOOKS GOOD AFTER INSTALLATION.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

MATERIAL AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
BODY: ALUMINUM 2117 /STAINLESS STEEL 302 (INOX A2/18-8)
PIN: ALUMINUM 2024/STAINLESS STEEL 304 (INOX A2/18-8)

FINISH SURFACE AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED
ANODIZED/CLEAN

1/4" DIAMETER	PARTNUMBER	(L) LENGTH		GRIP RANGE (G)
		(INCH)	(MM)	NOM.		MIN.		MAX.
				(INCH)	(MM)	(INCH)	(MM)	(INCH)	(MM)
UNIVERSAL HEAD	TSP6.4S-1	0.250	6.350	0.094	2.388	0.047	1.194	0.141	3.581
	TSP6.4S-2	0.281	7.137	0.125	3.175	0.078	1.981	0.172	4.369
	TSP6.4S-3	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP6.4S-4	O.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP6.4S-5	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP6.4S-6	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP6.4S-7	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP6.4S-8	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP6.4S-9	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP6.4S-10	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
	TSP6.4S-11	0.844	21.438	0.688	17.475	0.641	16.281	0.735	18.669
	TSP6.4S-12	0.906	23.012	0.750	19.050	0.703	17.856	0.797	20.244
	TSP6.4S-13	0.969	24.613	0.813	20.650	0.766	19.456	0.860	21.844
	TSP6.4S-14	1.031	26.187	0.875	22.225	0.828	21.031	0.922	23.419
	TSP6.4S-15	1.094	27.788	0.938	23.825	0.891	22.631	0.985	25.019
	TSP6.4S-16	1.156	29.362	1.000	25.400	0.953	24.206	1.047	26.594
	TSP6.4S-17	1.281	32.537	1.125	28.575	1.078	27.381	1.172	29.769
	TSP6.4S-18	1.531	38.887	1.375	34.925	1.328	33.731	1.422	36.119
BRAZIER HEAD	TSP6.4B-1	0.250	6.350	0.094	2.388	0.047	1.194	0.141	3.581
	TSP6.4B-2	0.281	7.137	0.125	3.175	0.078	1.981	0.172	4.369
	TSP6.4B-3	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP6.4B-4	O.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP6.4B-5	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP6.4B-6	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP6.4B-7	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP6.4B-8	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP6.4B-9	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP6.4B-10	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
	TSP6.4B-11	0.844	21.438	0.688	17.475	0.641	16.281	0.735	18.669
	TSP6.4B-12	0.906	23.012	0.750	19.050	0.703	17.856	0.797	20.244
	TSP6.4B-13	0.969	24.613	0.813	20.650	0.766	19.456	0.860	21.844
	TSP6.4B-14	1.031	26.187	0.875	22.225	0.828	21.031	0.922	23.419
	TSP6.4B-15	1.094	27.788	0.938	23.825	0.891	22.631	0.985	25.019
COUNTERSUNK HEAD*WITH CHAMFER	TSP6.4C-1	0.344	8.738	0.188	4.775	0.141	3.581	0.235	5.969
	TSP6.4C-2	O.406	10.312	0.250	6.350	0.203	5.156	0.297	7.544
	TSP6.4C-3	0.469	11.913	0.313	7.950	0.266	6.756	0.360	9.144
	TSP6.4C-4	0.531	13.487	0.375	9.525	0.328	8.331	0.422	10.719
	TSP6.4C-5	0.594	15.088	0.438	11.125	0.391	9.931	0.485	12.319
	TSP6.4C-6	0.656	16.662	0.500	12.700	0.453	11.506	0.547	13.894
	TSP6.4C-7*	0.719	18.263	0.563	14.300	0.516	13.106	0.610	15.494
	TSP6.4C-8*	0.781	19.837	0.625	15.875	0.578	14.681	0.672	17.069
	TSP6.4C-9	0.844	21.438	0.688	17.475	0.641	16.281	0.735	18.669
	TSP6.4C-10*	0.906	23.012	0.750	19.050	0.703	17.856	0.797	20.244
	TSP6.4C-11	0.969	24.613	0.813	20.650	0.766	19.456	0.860	21.844
	TSP6.4C-12	1.031	26.187	0.875	22.225	0.828	21.031	0.922	23.419
	TSP6.4C-13	1.094	27.788	0.938	23.825	0.891	22.631	0.985	25.019
	TSP6.4C-14	1.156	29.362	1.000	25.400	0.953	24.206	1.047	26.594
