3-8" SPEED PIN RIVET

3-8" SPEED PIN RIVET

ADVANTAGES OF SPEED PIN RIVET (DRIVE PIN RIVET):

SPEED PIN RIVET IS FAST AND EASY TO INSTALL.

NO SPECIAL INSTALLATION TOOL IS REQUIRED FOR SPEED PIN RIVET, JUST A HAMMER WILL DO.

VARIOUS MATERIALS ARE AVAILABLE FOR SPEED PIN RIVET.

VARIOUS HEAD STYLES ARE AVAILABLE FOR SPEED PIN RIVET.

SPEED PIN RIVET IS EASY TO UNINSTALL, AND IT WILL NOT DAMAGE THE APPLICATION SURFACE.

SPEED PIN RIVET CAN BE RUST RESISTANT.

SPEED PIN RIVET CAN BE APPLIED TO WIDE THICKNESS.

THE APPEARANCE LOOKS GOOD AFTER INSTALLATION.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

MATERIAL AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
BODY: ALUMINUM 2117 /STAINLESS STEEL 302 (INOX A2/18-8) / STEEL
PIN: ALUMINUM 2024 /STAINLESS STEEL 304 (INOX A2/18-8) /STEEL

FINISH SURFACE AVAILABLE FOR SPEED PIN RIVET (DRIVE PIN RIVET):
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED
ANODIZED/CLEAN

SPEED PIN RIVETS

3/8" DIAMETER	PART NUMBER	(L) LENGTH		GRIP RANGE (G)
		(INCH)	(MM)	NOM.		MIN.		MAN.
				(INCH)	(MM)	(INCH)	(MM)	(INCH)	(MM)
UNIVERSAL HEAD	TSP9.6S-1	0.500	12.700	0.188	4.775	0.125	3.175	0.250	6.350
	TSP9.6S-2	0.594	15.088	0.281	7.137	0.219	5.563	0.344	8.738
	TSP9.6S-3	0.688	17.475	0.375	9.525	0.313	7.950	0.437	11.100
	TSP9.6S-4	0.781	19.837	0.469	11.913	0.406	10.312	0.531	13.487
	TSP9.6S-5	0.875	22.225	0.562	14.275	0.500	12.700	0.625	15.875
	TSP9.6S-6	0.500	12.700	0.188	4.775	0.125	3.175	0.250	6.350
	TSP9.6S-7	0.594	15.088	0.281	7.137	0.219	5.563	0.344	8.738
	TSP9.6S-8	0.688	17.475	0.375	9.525	0.313	7.950	0.437	11.100
