STAINLESS STEEL(INOX)/STEEL BLIND RIVET

STAINLESS STEEL/ STEEL BLIND RIVETS
TS.SSAS. SERIES

ADVANTAGES OF STAINLESS STEEL/STEEL BLIND RIVET:

 STAINLESS STEEL/STEEL BLIND RIVETS PROVIDE STRONG HOLDING FOR APPLICATION.

 STAINLESS STEEL/STEEL BLIND RIVETS ARE LOW IN COST COMPARE WITH BOLT AND NUT.

 STAINLESS STEEL/STEEL BLIND RIVETS ARE IDEAL FOR WIDE RANGE APPLICATION.

 STAINLESS STEEL/STEEL BLIND RIVETS ARE AVAILABLE IN DOME, COUNTERSUNK OR LARGE FLANGE STYLE.

 STAINLESS STEEL/STEEL BLIND RIVETS ARE FAST AND EASY TO INSTALL.

 STAINLESS STEEL/STEEL BLIND RIVETS PROVIDE HIGH TENSILE AND SHEAR STRENGTH COMPARE WITH  ALUMINUM  OR STEEL.

 STAINLESS STEEL/STEEL BLIND RIVETS ARE IDEAL FOR RUST RESISTANCE APPLICATION.

 ★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

MATERIAL AVAILABLE FOR STAINLESS STEEL/ STEEL BLIND RIVETS TS.SSAS. SERIES:
RIVET:   STAINLESS STEEL 302/316 (INOX A2/A4/18-8/18-10)
SHAFT:  STEEL 1018 ~ 1022

FINISH SURFACE AVAILABLE:
RIVET:  SELF COULOURED
SHAFT:  CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED

TS.SSAS.	ITEM SIZE
STAINLESS STEEL RIVET STEEL SHAFT	A(HEAD DIA.)	B(BODY DIA.)	(INCH)	C(LENGTH)	(INCH)
TS.SSAS 4-2	6.4mm	3.2mm	1/8	4.80mm	.19
TS.SSAS 4-3				6.40mm	.25
TS.SSAS 4-4				8.00mm	.315
TS.SSAS 4-5				11.00mm	.43
TS.SSAS 4-6				12.30mm	.48
TS.SSAS 5-2	8.0mm	4.0mm	5/32	5.80mm	.23
TS.SSAS 5-3				7.00mm	.275
TS.SSAS 5-4				8.50mm	.335
TS.SSAS 5-5				10.00mm	.394
TS.SSAS 5-6				11.40mm	.488
TS.SSAS 5-8				13.00mm	.511
TS.SSAS 6-2	9.0mm	4.8mm	3/16	6.40mm	.25
TS.SSAS 6-4				10.50mm	.41
TS.SSAS 6-6				13.50mm	.53
TS.SSAS 6-8				16.50mm	.6
