BLIND RIVET SERIES:ALUMINUM/STEEL BLIND RIVETS

ALUMINUM/ STEEL BLIND RIVETS TS.AAS. SERIES

ADVANTAGES OF ALUMINUM/STEEL BLIND RIVET:

•  ALUMINUM/STEEL BLIND RIVETS PROVIDE STRONG HOLDING FOR APPLICATION.
• ALUMINUM/STEEL BLIND RIVETS ARE LOW IN COST COMPARE WITH BOLT AND NUT.
• ALUMINUM/STEEL BLIND RIVETS ARE IDEAL FOR WIDE RANGE APPLICATION.
• ALUMINUM/STEEL BLIND RIVETS ARE AVAILABLE IN DOME, COUNTERSUNK OR LARGE FLANGE STYLE.
• ALUMINUM/STEEL BLIND RIVETS ARE FAST AND EASY TO INSTALL.
• ALUMINUM/STEEL BLIND RIVETS ARE IDEAL FOR RUST RESISTANCE APPLICATION.
• ALUMINUM/STEEL BLIND RIVETS ARE IDEAL FOR LIGHT WEIGHT USAGE.
•

• ★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

 MATERIAL AVAILABLE FOR ALUMINUM/ STEEL BLIND RIVETS TS.AAS. SERIES:

RIVET:   ALUMINUM 5050
SHAFT: STEEL 1018 ~ 1022

FINISH SURFACE AVAILABLE:
RIVET:   SELF COULOUR/ COLOURED IN YELLOW/ BLACK/ WHITE/ RED...ETC
SHAFT:  CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED

　



TS.AAS.	ITEM SIZE
ALUMINUM RIVET STEEL SHAFT	A(HEAD DIA.)	B(BODY DIA.)	(INCH)	C(LENGTH)	(INCH)
TS.AAS 3-2	4.5mm	2.4mm	3/32	5.80mm	.23
TS.AAS 3-3				7.40mm	.30
TS.AAS 3-4				8.40mm	.33
TS.AAS 4-1	6.4mm	3.2mm	1/8	4.80mm	.19
TS.AAS 4-2				6.40mm	.25
TS.AAS 4-3				8.00mm	.315
TS.AAS 4-4				9.60mm	.38
TS.AAS 4-5				11.50mm	.45
TS.AAS 4-6				12.70mm	.50
TS.AAS 4-8				16.10mm	.63
TS.AAS 5-1	8.0mm	4.0mm	5/3	5.80mm	.23
TS.AAS 5-2				7.00mm	.275
TS.AAS 5-3				8.50mm	.335
TS.AAS 5-4				10.00mm	.394
TS.AAS 5-5				11.40mm	.488
TS.AAS 5-6				13.00mm	.511
TS.AAS 5-8				16.50mm	.65
TS.AAS 5-10				19.50mm	.77
TS.AAS 6-1	9.0mm	4.8mm	3/16	6.40mm	.25
TS.AAS 6-2				7.40mm	.30
TS.AAS 6-3				9.60mm	.38
TS.AAS 6-4				11.00mm	.44
TS.AAS 6-5				12.70mm	.50
TS.AAS 6-6				14.50mm	.57
TS.AAS 6-8				17.50mm	.69
TS.AAS 6-10				20.40mm	.80
TS.AAS 6-12				24.00mm	.95
