STEEL/ STEEL BLIND RIVETS TS.SAS. SERIES

STEEL/ STEEL BLIND RIVETS TS.SAS. SERIES

ADVANTAGES OF STEEL/STEEL BLIND RIVET:

STEEL/STEEL BLIND RIVETS PROVIDE STRONG HOLDING FOR APPLICATION.

STEEL/STEEL BLIND RIVETS ARE LOW IN COST COMPARE WITH BOLT AND NUT.

STEEL/STEEL BLIND RIVETS ARE IDEAL FOR WIDE RANGE APPLICATION.

STEEL/STEEL BLIND RIVETS ARE AVAILABLE IN DOME, COUNTERSUNK OR LARGE FLANGE STYLE.

STEEL/STEEL BLIND RIVETS ARE FAST AND EASY TO INSTALL.

STEEL/STEEL BLIND RIVETS PROVIDE HIGH TENSILE AND SHEAR STRENGTH COMPARE WITH ALUMINUM.

STEEL/STEEL BLIND RIVETS ARE IDEAL FOR RUST RESISTANCE APPLICATION.

MATERIAL AVAILABLE FOR STEEL/ STEEL BLIND RIVETS TS.SAS. SERIES:
RIVET:   STEEL 1006
SHAFT: STEEL 1018 ~ 1022

FINISH SURFACE AVAILABLE:
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED/ CR3 ZINC NICKEL PLATED ... ETC.
COLOURED: YELLOW/ RED/ BLACK/ WHITE ... ETC.　

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST



TS.SAS.	ITEM SIZE
STEEL RIVET STEEL SHAFT	A(HEAD DIA.)	B(BODY DIA.)	(INCH)	C(LENGTH)	(INCH)
TS.SAS 3-2	4.5mm	2.4mm	3/32	5.80mm	.23
TS.SAS 3-3				7.40mm	.30
TS.SAS 3-4				8.40mm	.33
TS.SAS 4-1	6.4mm	3.2mm	1/8	4.80mm	.19
TS.SAS 4-2				6.40mm	.25
TS.SAS 4-3				8.00mm	.315
TS.SAS 4-4				9.60mm	.38
TS.SAS 4-5				11.50mm	.45
TS.SAS 4-6				12.70mm	.50
TS.SAS 4-8				16.10mm	.63
TS.SAS 5-1	8.0mm	4.0mm	5/32	5.80mm	.23
TS.SAS 5-2				7.00mm	.275
TS.SAS 5-3				8.50mm	.335
TS.SAS 5-4				10.00mm	.394
TS.SAS 5-5				11.40mm	.488
TS.S AS 5-6				13.00mm	.511
TS.SAS  5-8				16.50mm	.65
TS.SAS 5-10				19.50mm	.77
TS.SAS 6-1	9.0mm	4.8mm	3/16	6.40mm	.25
TS.SAS 6-2				7.40mm	.30
TS.SAS 6-3				9.60mm	.38
TS.SAS 6-4				11.00mm	.44
TS.SAS 6-5				12.70mm	.50
TS.SAS 6-6				14.50mm	.57
TS.SAS 6-8				17.50mm	.69
TS.SAS 6-10				20.40mm	.80
TS.SAS 6-12				24.00mm	.95
