CLINCHING PARTS: TSC 5 SELF-CLINCHING LOCK NUTS
ADVANTAGES OF CLINCHING PARTS:
- PROVIDE STRONG THREADS IN METAL AS THIN AS 020" / .51 MM.
- MAY BE INSTALLED USING ANY PARALLEL ACTING SQUEEZING FORCE.
- PROVIDE HIGH PUSHOUT AND TORQUE-OUT RESISTANCE.
- DO NOT REQUIRE SPECIAL HOLE PREPARATION, SUCH AS CHAMFERING AND DEBURRING.
- REVERSE SIDE OF METAL SHEET REMAINS FLUSH.
- NO RETAPPING NECESSARY AFTER APPLICATION.
- LOW INSTALLED COSTS.
★NUTS：
NUTS WITH THREAD STRENGTHS GREATER THAN MILD STEEL SCREWS ARE COMMONLY USED WHEREVER STRONG INTERNAL THREADS ARE NEEDED FOR COMPONENT ATTACHMENT OF FABRICATION ASSEMBLY.
NUTS WITH THREAD STRENGTHS GREATER THAN MILD STEEL SCREWS ARE COMMONLY USED WHEREVER STRONG INTERNAL THREADS ARE NEEDED FOR COMPONENT ATTACHMENT OF FABRICATION ASSEMBLY.
★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST
SC 5 SELF-CLINCHING LOCK NUTSlf-
Type SC
|
Type ST
| Type S |
| ||||||||||||||||
|
L
LENGTH ± 0.20 |
A
± 0.20 |
H
± 0.10 |
D
+0.00 -0.08 |
T
± 0.10 |
P
± 0.10 | ||||||||||
| M3x0.5 |
4
|
6
|
8
|
10
|
12
|
14
|
16
|
18
|
20
|
7.20
|
0.55
|
6.18
|
5.60
|
0.50
| ||
| M4x0.7 |
6
|
8
|
10
|
12
|
14
|
16
|
18
|
20
|
8.20
|
0.55
|
7.18
|
6.60
|
0.50
| |||
| M5x0.8 |
8
|
10
|
12
|
14
|
16
|
18
|
20
|
8.20
|
0.55
|
7.18
|
6.60
|
0.50
| ||||
| S | 2 | 3 | 4 | 6 | 8 | 8 | 8 | 8 | 8 | |||||||
