SELF TAPPING THREADED INSERT MANUAL INSTALLATION TOOLS

SELF TAPPING THREADED INSERT

MANUAL INSTALLATION TOOLS

 SELF TAPPING THREADED INSAERT is strong and

reusable permanent thread , and need to tap a hole to

install these inserts. Taps and installs in one easy step,

and can saving time,money and labor. It can endure

vibration without loosening.

Three lateral cutting bores make for an easy self-tapping

installation, and provide a connection for highly resistant to vibration.

SELF TAPPING THREWADED INSAERTS allow permanent threads

to be produced in a wide range

of components and materials.

MATERIAL AVAILABLE FOR THREE HOLE-THICK WALL:

Aluminum, Aluminum Alloy,

Steel, Stainless Steel, Brass.

ADVANTAGE OF SELF TAPPING THREADED INSERT:

•  High pull-out strength
•  High torque resistance
•  Strong Wear resistance thread
•  Fast, easy installation
•  Extreme vibration resistance

SELF TAPPING THREADED INSERT

MANUAL INSTALLATION TOOLS

INCH SIZE		METER SIZE		LENGTH	SQUARE ACROSS FLAT	COLLAR ACROSS FLAT
THREAD	PART NO.	THREAD	PART NO.	I1
2-56	TSIT0256	M2.5	TSMT025	2.165	0.197"	7mm
4-40	TSIT0440	M3	TSMT030	2.165	0.197"	7mm
6-32	TSIT0632	M3.5	TSMT035	2.362	0.197"	7mm
8-32	TSIT0832	M4	TSMT040	2.362	0.197"	7mm
10-24**	TSIT1024	M5	TSMT050	2.953	0.315"	13mm
1/4-20**	TSIT0420	M6	TSMT060	2.953	0.315"	13mm
5/16-18	TSIT0518	M8	TSMT080	2.953	0.315"	13mm
3/8-16	TSIT0616	M10	TSMT010	3.740	0.492"	19mm
7/16-14	TSIT71614	M12	TSMT012	3.740	0.492"	19mm
1/2-13	TSIT01213	M14	TSMT014	3.740	0.492"	19mm

STEP 1.DRILL THE HOLE, SCREW INSERT ON TO THE TOOL WITH SLOT POINTING DOWNWARD

STEP 2.MAINTAINING THE TOOL PERPENDICULARITY, ROTATE THE TAP CLOCKWISE & SCREW ITS WAY INTO MATERIAL

STEP 3.  BACK OUT THE TOOL ANTI-CLOCKWISE & IT WILL AUTOMATICALLY RELEASED FROM THE INSERT

1. HOLE SIZE:

RECOMMENDED HOLE SIZE IS INDICATED ON EACH DATA SHEET AND IS INTENDED TO BE FOR REFERENCE ONLY. HOLE SIZE MAY NEED TO BE INCREASED OR DECREASED DEPENDING ON BASE MATERIAL, INSTALLATION TORQUE OR PERFORMANCE REQUIRED. OPTIMUM HOLE SIZE SHOULD BE DETERMINED BY REQUESTING SAMPLES & INSTALLING THEM IN THE INTENDED MATERIAL.

2. HOLE DEPTH:

IN THRU HOLE APPLICATIONS THE INSERT LENGTH SHOULD NOT EXCEED THE MATERIAL THICKNESS. IN BLIND HOLE APPLICATIONS THE HOLE DEPTH SHOULD BE 1.2XINSERT LENGTH AND THIS VALUE IS INDICATED ON MOST DATA SHEETS.

3. COUNTERSINK

A 60°COUNTERSINK IS REQUIRED FOR MOST MATERIALS TO INSURE A FLUSH SURFACE AFTER INSTALLATION.

4. WALL THICKNESS

WALL THICKNESS SHOULD BE 0.35 TO 0.5 X HOLE DIAMETER DEPENDING ON BASE MATERIAL.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST
