FULL-HEXAGON RIVET NUT

FULL-HEXAGON RIVET NUT

FHSM, FHSI SERIES

FULL-HEXAGON WITH SMALL FLANGE RIVET NUT

HEX FLANGE, ROUND INTERNAL HOLE, OPEN END

THREAD SIZE	PART NO.	HOLE  SIZE   +0.1/-0.0	D(mm)+0.0/-0.1	L(mm)+/-0.4	A(mm)+/-0.3	H(mm)+0.15/-0.05	GRIP RANGE
M4X0.7	FHSM4	6.1	5.9	10.2	6.9	0.5	0.5-2.5
M5X0.8	FHSM5	7.1	6.9	12.0	7.8	0.5	0.5-3.0
M6X1.0	FHSM6	9.1	8.9	15.2	10.0	0.5	0.5-3.3
M8X1.25	FHSM8	11.1	10.9	17.8	12.0	0.6	0.5-3.3
M10X1.5	FHSM10	13.1	12.9	21.0	14.6	0.8	0.5-3.5

THREAD SIZE	PART NO.	HOLE  SIZE+0.004/-0.0	D(inch)+0.0/-0.004	L(inch)±0.015	A(inch)±0.012	H(inch)+0.006 / -0.002	GRIP RANGE
UNC 8-32	FHSI 832	.240	.232	.402	.272	.02	0.02-0.098
UNC10-24	FHSI1024	.280	.272	.472	.307	.02	0.02-0.118
UNC 1/4-20	FHSI 420	.358	.350	.598	.394	.02	0.02-0.130
UNC 5/16-18	FHSI 518	.437	.429	.701	.472	.024	0.02-0.130
UNC 3/8-16	FHSI 616	.516	.508	.827	.575	.031	0.02-0.138

　

FHBM, FHBI SERIES

FULL-HEXAGON WITH BIG FLANGE RIVET NUT

FLAT HEAD, ROUND INTERNAL HOLE, OPEN END

THREAD SIZE	PART NO.	HOLE  SIZE+0.1/-0.0	D(mm)+0.0/-0.1	L(mm)±0.4	A(mm)±0.3	H(mm)+0.15/-0.05	GRIP RANGE
M4X0.7	FHBM4	6.1	5.9	10.7	9.0	0.9	0.5-2.5
M5X0.8	FHBM5	7.1	6.9	13.7	10.0	0.9	0.5-3.0
M6X1.0	FHBM6	9.1	8.9	16.0	13.0	1.5	0.5-3.3
M8X1.25	FHBM8	11.1	10.9	18.0	16.0	1.5	0.5-3.3
M10X1.5	FHBM10	13.1	12.9	21.0	19.0	2.0	0.5-3.5

THREAD SIZE	PART NO.	HOLE  SIZE+0.004/-0.0	D(inch)+0.0/-0.004	L(inch)±0.015	A(inch)±0.012	H(inch)+0.006/-0.002	GRIP RANGE
UNC 8-32	FHBI832	.240	.232	.421	.354	.035	0.02-0.098
UNC10-24	FHBI1024	.280	.272	.539	.394	.035	0.02-0.118
UNC 1/4-20	FHBI420	.358	.350	.630	.512	.059	0.02-0.130
UNC 5/16-18	FHBI518	.437	.429	.709	.630	.059	0.02-0.130
UNC 3/8-16	FHBI616	.516	.508	.827	.748	.079	0.02-0.138

NOTE: K= KNURLED  BODY

★CLICK ME TO SEE HOW TO INSTALL THE BLIND RIVET NUT

MATERIAL AVAILABLE:
STEEL, STAINLESS STEEL 302( INOX A2/18-8) AND 316 ( INOX A418-10), BRASS, ALUMINUM 5056

SURFACE FINSIH AVAILABLE:
STEEL: CR3 WHITE/YELLOW/BLACK ZINC PLATED, CR3 ZINC NICKEL PLATED, NICKEL PLATED
STAINLESS STEEL: CLEAN OR PASSIVATED.
BRASS: CLEAN
ALUMINUM: CLEAN

CHARACTERISTICS OF SMALL FLANGE BLIND RIVET NUT

• THE BLIND RIVET NUT HAS BEEN SPECIALLY DEVELOPED TO GIVE DESIGNERS A STRONG AND VIBRATION- PROOF STEEL THREAD IN THIN SHEET APPLICATIONS.
• THE BLIND RIVET NUT CAN BE USED TO ASSEMBLE TWO OR MORE SHEETS OF VARIOUS MATERIALS (STEEL, ALUMINUM, WOOD, PLASTIC, ETC.) AND CAN BE FIXED BY A SCREW.
• THE HEAD OF SMALL FLANGE BLIND RIVET NUT IS IN A COUNTERSUNK SHAPE THAT MAKES THE APPLICATION SURFACE FLAT AND SMOOTH AFTER INSTALLATION.
• THE BLIND RIVET NUT IS FAST AND CONVENIENT IN INSTALLATION.
• APPLICATION SURFACE FINISH WILL NOT BE DAMAGED AFTER INSTALLTION OF BLIND RIVET NUT.

THE BLIND RIVET NUT OFFERS THE FOLLOWING ADVANTAGES

• EASY AND FAST INSTALLATION.
• HIGH TORQUE AND STRONG THREADS ARE COMPARABLE TO NORMAL FASTENERS.

ASSEMBLY APPLICATIONS

• AUTOMATIVE
• ELECTRICAL ENGINEERING
• SHEET METAL
• GENERAL LIGHT FABRICATION

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST
