SPECIAL BLIND RIVET NUT: SERRATION UNDER HEAD-BEM6


SERRATION UNDER HEAD-BEM6


THE BLIND RIVET NUT HAS BEEN SPECIALLY DEVELOPED TO GIVE DESIGNERS A STRONG AND VIBRATION- PROOF STEEL THREAD IN THIN SHEET APPLICATIONS.
THE BLIND RIVET NUT CAN BE USED TO ASSEMBLE TWO OR MORE SHEETS OF VARIOUS MATERIALS (STEEL, ALUMINUM, WOOD, PLASTIC, ETC.) AND CAN BE FIXED BY A SCREW.
THREAD SIZED(mm)
+0.0/-0.1
 L(mm)
±0.4
A(mm)
±0.3
H(mm)
+0.15/-0
GRIP RANGE
M6X1.09.014.513.01.51.0-3.5
THREAD SIZED(inch)
+0.0/-0.004
L(inch)
±0.015
A(inch)
±0.012
H(inch)
+0.006/-0
GRIP RANGE
M6X1.0.354.571.512.0590.039-0.138
MATERIAL AVAILABLE:
STEEL.
SURFACE FINSIH AVAILABLE:
CR3 YELLOW ZINC PLATED.
ASSEMBLY APPLICATIONS:
  • AUTOMATIVE
  • ELECTRICAL ENGINEERING
  • STEET METAL
  • GENERAL LIGHT FABRICATION
OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST
