HALF HEX W. SMALL FLANGE RIVET NUT

HALF HEX W.SMALL FLANGE RIVET NUT　: HSM, HSI

HSM, HSI SERIES

HALF-HEXAGON WITH SMALL FLANGE BERYNUT

HEX FLANGE, HEX INTERNAL HOLE, OPEN END

THREAD SIZE	PART NO.	HOLE SIZE+0.1/-0.0	D(mm)+0.0/-0.1	L(mm)±0.4	A(mm)±0.3	H(mm)+0.15/-0.05	GRIP RANGE
M4X0.7	HSM4	6.45	6.35	10.4	7.0	0.4	0.5-2.0
M5X0.8	HSM5	7.20	7.1	11.8	8.0	0.6	0.5-3.0
M6X1.0	HSM6	9.60	9.5	14.6	10.6	0.6	0.5-3.0
M8X1.25	HSM8	10.60	10.5	16.0	11.5	0.6	0.5-3.5
M10X1.5	HSM10	12.70	12.6	18.5	14.0	0.6	0.7-3.8
THREAD SIZE	PART NO.	HOLE SIZE+0.004/-0.0	D(inch)+0.0/-0.004	L(inch)±0.015	A(inch)±0.012	H(inch)+0.006/-0.002	GRIP RANGE
UNC 8-32	HSI 832	.254	.250	.409	.376	.016	0.02-0.079
UNC 10-24	HSI 1024	.280	.279	.465	.315	.024	0.02-0.118
UNC 1/4-20	HSI 420	.378	.374	.575	.417	.024	0.02-0.118
UNC 5/16-18	HSI 518	.417	.413	.630	.453	.024	0.02-0.138
UNC 3/8-16	HSI 616	.500	.496	.728	.551	.024	0.028-0.150

NOTE: K= KNURLED  BODY
★CLICK ME TO SEE HOW TO INSALL THE BLIND RIVET NUT
MATERIAL AVAILABLE:
STEEL, STAINLESS STEEL 302( INOX A2) AND 316 ( INOX A4), BRASS, ALUMINUM 5056
SURFACE FINSIH AVAILABLE:
STEEL: CR3 WHITE/YELLOW/BLACK ZINC PLATED, CR3 ZINC NICKEL PLATED, NICKEL PLATED
STAINLESS STEEL: CLEAN OR PASSIVATED.
BRASS: CLEAN
ALUMINUM: CLEAN
CHARACTERISTICS OF SMALL FLANGE BLIND RIVET NUT

• THE BLIND RIVET NUT HAS BEEN SPECIALLY DEVELOPED TO GIVE DESIGNERS A STRONG AND VIBRATION- PROOF STEEL THREAD IN THIN SHEET APPLICATIONS.
• THE BLIND RIVET NUT CAN BE USED TO ASSEMBLE TWO OR MORE SHEETS OF VARIOUS MATERIALS (STEEL, ALUMINUM, WOOD, PLASTIC, ETC.) AND CAN BE FIXED BY A SCREW.
• THE HEAD OF SMALL FLANGE BLIND RIVET NUT IS IN A COUNTERSUNK SHAPE THAT MAKES THE APPLICATION SURFACE FLAT AND SMOOTH AFTER INSTALLATION.
• THE BLIND RIVET NUT IS FAST AND CONVENIENT IN INSTALLATION.
• APPLICATION SURFACE FINISH WILL NOT BE DAMAGED AFTER INSTALLTION OF BLIND RIVET NUT.

THE BLIND RIVET NUT OFFERS THE FOLLOWING ADVANTAGES

• EASY AND FAST INSTALLATION.
• HIGH TORQUE AND STRONG THREADS ARE COMPARABLE TO NORMAL FASTENERS.

ASSEMBLY APPLICATIONS

• AUTOMATIVE
• ELECTRICAL ENGINEERING
• SHEET METAL
• GENERAL LIGHT FABRICATION

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST
