BOLT (SCREW) RIVET NUT

BOLT RIVET NUT is easy and fast in installation with handy tool and provides the high torque, strong threads in comparing wuth normal fasteners. The Bolt Rivet Nut features a round serrated body that installs in the same fashion as a Blind Rivet Nut.

The Bolt Rivet Nut is an ideal alternative to weld studs and clinch stud. It is able to reduce assembling time and improve output.

The installation of bolt rivet nut are faster and easier, it can elminate the need to access the back side of the workpiece. Install all into galvanised or pre-painted material without damaging surface. The bolt rivet nut can elminate the thread masking after finsihing‧  It can install into material as thin as .020 or 0.5mm and install intop a wide range of material type or thickness.





ISL (installed Stud Length) Dimension
Is Based On Max. Grip Installation.



To Calculate The Actual Isl In A Specific
Grip, Use The Following Formula:

Max. Grip - Actual Grip = Grip Difference

ISL + Grip Difference = Actual Isl

 ★CLICK ME
TO SEE HOW TO INSTALL THE BOLT RIVET NUT　
MATERIALS ARE AVAILABLE FOR BOLT RIVET NUT:
STAINLESS STEEL 302/304 (A2/18-8), 316(A4/18-10), STEEL, ALUMINUM 5056/6061, BRASS C2600
CHARACTERISTCS OF BOLT (SCREW) RIVET NUT:

• BOLT (SCREW) RIVET NUT IS EASY AND FAST IN INSTALLATION WITH HANDY TOOL.
• BOLT (SCREW) RIVET NUT PROVIDES HIGH TORQUE AND STRONG THREADS IN COMPARING WITH NORMAL FASTENERS.
• WELDING PROCESS IN NOT REQUIRED IN INSTALLING BOLT (SCREW) RIVET NUT.
• BOLT (SCREW) RIVET NUT IS ABLE TO REDUCE ASSEMBLING TIME AND IMPROVE OUTPUT.
• BOLT (SCREW) RIVET NUT IS ABLE TO PROVIDE A STRONG BINDING SUPPORT ON COMBINATION APPLICATIONS.
• BOLT (SCREW) RIVET NUT WILL NOT LOOSEN FROM VIBRATING OBJECTS ONCE ITS' INSTALLED.
• BOLT (SCREW) IS ALREADY COMBINED WITH BLIND RIVET NUT BEFORE INSTALLATION, SO IT IS NOT NECESSARY TO INSTALL THE SCREW ON THE BLIND RIVET NUT.
• BOLT (SCREW) AND BLIND RIVET NUT IS COMBINED RIGIDLY TO SUIT VIBRATING ENVIRONMENT.
• BOLT (SCREW) RIVET NUTS ARE AVAILABLE IN BOTH UNC AND ISO DIMENSION.

Fasteners

Fasteners are hardware device that mechanically joins or affixes two or more objects together. Fasteners can also be used to close a container such as a bag, a box, or an envelope and they may involve keeping together the sides of an opening of flexible material, attaching a lid to a container, etc.Fasteners used in these manners are often temporary, in that they may be fastened and unfastened repeatedly.

Furniture supplied in flat-pack form often uses cam dowels locked by cam locks, also known as conformat fasteners.

Items like a rope, string, wire, cable, chain, or plastic wrap may be used to mechanically join objects; but are not generally categorized as fasteners because they have additional common uses. Likewise, hinges and springs may join objects together, but are ordinarily not considered fasteners because their primary purpose is to allow articulation rather than rigid affixment.

Other alternative methods of joining materials include welding,taping,crimping,soldering, brazing, cementing, or the use of other adhesives.

There are three major steel fasteners using in industries. Stainless Steel, Carbon Steel and Alloys Steel

Major Grade using in Stainless Steel Fasteners. 200 series 300 series 400 series.

(reference by Wikipedia)

BLIND JACK NUT

BLIND JACK NUT

THE BLIND JACK NUT IS AN ECONOMICAL BLIND FASTENER DESIGNED FOR ASSEMBLY LIND USE IN THIN, SOFT OR BRITTLE MATERIALS. WHEN TIGHTENED, THEIR BODY COLLAPSES TO FORM LEGS WHICH GRIP THE INSIDE OF THE MOUNTING SURFACE, LEAVING A PERMANENT REUSABLE THREADED INSERT. STANDARD BLIND JACK NUT ARE MANUFACTURED OF STEEL WITH A COMMERCIAL ZINC PLATING. ALL BLIND JACK NUTS CAN BE SUPPLIED WITH BRASS COATED FLANGES WHICH ASSIST GALVANIC CORROSION CONCERNS.

　

　

1. THREAD INSERT ONTO THE MANDREL OF INSTALLATION TOOL, THEN INSERT ALL THE WAY IN TO PREDRILLED HOLE UNTIL FLANGE IS FIRMLY AGAINST MOUNTING SURFACE	2. FULLY  COLLAPSE INSERT, THEN REMOVE TOOL	3. PASS MACHINE SCREW THROUGH PART TO BE FASTENED, THEN TIGHTEN UNTIL SNUG

　

PART NO.	THREAD SIZE.	SCREW	GRIP RANGE (mm)	HOLE SIZE (mm)	TOTAL LENGTH (mm)
TJM01	M4	M4X25	0-5	8	17
TJM02	M4	M4X30	5-10	8	22
TJM03	M5	M5X26	0-5	10	18
TJM04	M5	M5X31	5-10	10	23
TJM05	M6	M6X27	0-5	11	18
TJM06	M6	M6X32	5-10	11	23
TJU01	1/8	6-32X25	0-5	8	17
TJU02	1/8	6-32X30	5-10	8	22
TJU03	3/16	10-24X26	0-5	10	18
TJU04	3/16	10-24X31	5-10	10	23
TJU05	1/4	1/4-20X27	0-5	11	18
TJU06	1/4	1/4-20X32	5-10	11	23

FEATURES：

• FASTENS IN BLIND HOLES
• FASTENS SECURELY DESPITE BURRS & UNEVEN SUBSTRATES
• NOT HOLE SIZE SENSITIVE
• SUITABLE FOR WIDE GRIP RANGE

BLIND JACK NUT TOOL  AN ECONOMICAL, EASY TO USE TOOL FOR LOW-VOLUME INSTALLATION IN ANY MATERIAL. THREAD PULL-ROD INTO BLIND JACK NUT, INSERT INTO HOLE, AND SQUEEZE HANDLES TO SET. INTERCHANGEABLE PULL-OUT RODS AVAILABLE TO SET ALL SIZES. PNEUMATIC BLIND JACK NUT TOOL ALSO AVAILABLE.

MATERIAL AVAILABLE FOR BLIND JACK NUT:
STEEL

　

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

spoke nipple

A spoke nipple holds a bicycle wheel's rim to each spoke and it is a headed cylinder with threading on the inside through part of its length. When the other end of the nipple points inwards towards the hub, the nipples will fit in holes in the rim, so that the head of the nipple is on th outermost part of the rim .

Since spoke threading and nipple threading must match, boxes of spokes usually include a like number of nipples. Weight savings or the need for great strength due to building a wheel with few spokes might call for obtaining different nipples than those shipped with the spokes. Standard materials for nipples are brass and aluminum.

Brass is heavier but more durable and less prone to corrosion, rounding of flats when tightening, and breaking; aluminum is lighter. If using aluminum nipples, the spokes should be long enough to engage the full length of spoke nipple threads so that the load is carried from spoke to the top of the nipple. If the spoke is only part way into the nipple, the nipple carries the tension load and is prone to breaking from fatigue failure. Also, with aluminum nipples care and a good spoke wrench are needed to avoid rounding the flats while tightening.

If the underside of the nipple has the traditional conical shape, the nipple tends to adjust perpendicular to the nipple seat of the rim when the spoke is tensioned. This can cause a marked bend in the spoke where it exits the nipple, especially on small wheels with large diameter hubs, and subsequent early spoke failures. Nipples with a spherical contact surface to the rim that do not exhibit this tendency have been introduced. (reference by Wikipedia)

http://www.imperialrivet.com/en/products/?method=listing&sid=74

FOLDING BLIND RIVET

FOLDING BLIND RIVET



	D	HOLE SIZE	L	W	H		E		GRIP RANGE	STRENGTH(KG-F)
					DOME	CSK	DOME	CSK		TENSILE	SHEAR
P/N	RIVET DIA.	DRILLING DIA.	LENGTH	MANDREL DIA.	FLANGE DIA.		FLANGE DIA.
TF4143	3.2(1/8")	3.3	8.0	1.8	6.4	5.5	1.0	0.7	1.0~4.8	95	70
TF4345			11.5						4.0~8.0
TF5254	4.0(5/32")	4.1	10.5	2.15	8.0	6.2	1.27	1.0	1.2~6.4	160	115
TF6264			11.0						1.5~6.0
TF6466	4.8(3/16")	5.0	15.0	2.6	9.4	8.6	1.52	1.4	4.0~9.0	230	160
TF6668			18.0						6.4~12.8

ALL MEASUREMENTS ARE IN mm

MATERIAL AVAILABLE FOR STRETCH FOLDING BLIND RIVETS:
ALUMINUM 5052/ MANDREL MATERIAL: STEEL/ ZINC PLATED

SUITABLE APPLICATION:

• AUTOMOBILES, MOTORCYCLES, ELECTRICAL APPLIANCES, LIGHTING FIXTURES, ETC.
• MAKES THE GAP OF JOINING OBJECTS EXPAND FIRST THEN RIVETS THEM CLOSELY.
• IT WILL NOT BE LOOSENED BY SHANK.
• THE INNER AND OUTER JOINS ARE GOOD LOOKING.
• FINISH AVAILABLE IN A MULTIPLE OF COLORS.

★OTHER SIZE, MATERIAL ARE AVAILABLE UPON REQUEST

Steel Blind Rivet

Blind rivets  as know as pop rivets, are tubular and supplied with a mandrel through the center. The blind rivet body is inserted in a hole in the materials to be joined. The tool is actuated and the jaws of the power operated or manual riveting tool grips the mandrel of the rivet. The blind rivet is set by pulling the mandrel head into the rivet body, expanding it, and forming a strong, tight, reliable joint. At a predetermined setting force, the mandrel breaks and falls away.

Steel Blind Rivets are using high grade steel material and high strebgth with excellent load bearing capabilities. It provide strong and virbartion resistant joints to the user application. Steel Blind Rviets provides strong holding for applcation and  low in cost compare with Bolt and Nut. Steel Blind Rivet are ideal for wide range application and  available in dome, countersunk or large flange style. Steel Blind Rivet are fast and easy to install and ideal for rust resistance appication. Steel Blind Rivet provides high tensile and shear strength compare with aluminum.



MATERIAL AVAILABLE FOR STEEL/ STEEL BLIND RIVETS TS.SAS. SERIES:

RIVET:   STEEL 1006
SHAFT: STEEL 1018 ~ 1022

FINISH SURFACE AVAILABLE:
PLATING: CR3 WHITE ZINC PLATED/ CR3 YELLOW ZINC PLATED/ CR3 BLACK ZINC PLATED/ CR3 ZINC NICKEL PLATED ... ETC.
COLOURED: YELLOW/ RED/ BLACK/ WHITE ... ETC.　





Stainless Steel Blind Rivet

Stainless Steel Blind Rivet is  incorporated with a large blind head are excellent for thin sheet materials and corrosion resistant. It is meticulously fabricated with high emphasis on quality to make them free from all drawbacks and can be availed by our clients at leading market rates.

The advantage of Stainless Steel Blind Rivet:

• Provide strong holding for allpicaton
• Low in cost compare with bolt and nut.
• Ideal for wide range application.
• Available in dome, countersunk or large style.
• Fast and easy to install.
• Provide high tensile and shear strengt compare with alumiunm or steel.
• Ideal for rust resistance application.
• High strength and corrosion resistant
